Gel batteries are an innovative battery technology that combines the high performance of traditional lead-acid batteries with the stability and safety of advanced gel electrolyte technology. By introducing special gel additives into the electrolyte, this type of battery forms a stable gel structure, which greatly improves the performance and service life of the battery.
* High-tin multi-element alloy grids and special lead paste formulations improve the corrosion resistance of the grids.
* Nano-silica gel electrolyte solves the problem of electrolyte stratification and extends the battery's cycle life.
* With a large heat capacity, it reduces the risk of thermal runaway, is less likely to dry out, and can be used in relatively harsh environments.
* It has a high gas recombination efficiency and less acid mist leakage.
* It has a strong ability to recover from deep discharges.
* It has a low self-discharge rate and a long transportation and storage period.
* High-strength ABS shells offer higher safety during use.
Product model
Battery model list | |||||
Series model | Reference size(±3mm) | Terminal | |||
Long | Wide | High | Total height | ||
(mm) | (mm) | (mm) | (mm) | ||
12V18Ah | 181 | 76 | 166 | 166 | L/Round |
12V24Ah | 165 | 125 | 174 | 174 | M6 |
12V33Ah | 195 | 130 | 161 | 166 | M6 |
12V40Ah | 196 | 166 | 175 | 175 | M6 |
12V55Ah | 229 | 138 | 209 | 214 | M6 |
12V65Ah | 350 | 167 | 174 | 174 | M8 |
12V75Ah | 260 | 168 | 213 | 218 | M8 |
12V100Ah | 330 | 173 | 216 | 222 | M8 |
12V120Ah | 406 | 174 | 209 | 237 | M8 |
12V150Ah | 484 | 170 | 240 | 240 | M8 |
12V200Ah | 521 | 238 | 218 | 223 | M8 |
12V250Ah | 520 | 267 | 220 | 225 | M8 |
Product implementation standard GB/T 19639.1-2014 general valve-controlled lead-acid battery Product implementation standard GB/T 19638.1-2014 Fixed valve-controlled lead-acid battery Battery terminal type can be freely changed according to customer requirements |
Curve picture
